Department of Electronics and Communication Engineering
Lab Facilities
- Circuits and Devices Laboratory
- 0-30V RPS
- 0-30V Voltmeter
- 0-10V Voltmeter
- 0-1V Voltmeter
- 0-30mA Ammeter
- 0-100mA Ammeter
- CRO (30 MHz)
- Function Generator(1MHz)
- Decade Resistance Box
- Decade Capacitance Box
- Decade Inductance Box
- Analog Electronics Lab -I & II
- CRO
- Function generator/Signal Generator
- RPS
- DC Voltmeter
- Step-down Transformer
- DC Ammeter
- Decade Inductance Box
- Decade Capacitance Box
- Decade Resistance Box
- Digital Multimeter
- Digital Electronics Laboratory
- Digital IC Trainer Kit
- Digital IC Tester
- Computer with Xilinx Software installed
- IC’s required for Experiments
- Linear Integrated Circuits Laboratory
- CRO (30MHz)
- Function generator(1MHz)
- Step-down Transformer
- Power supply (0-30V)
- Computer(PSPICE Installed)
- OP-AMPS, 555 IC Timer
- Microprocessor and Microcontroller Laboratory
- Microprocessor trainer kit with power supply (Model ALS-SDA-85ME)
- Microprocessor trainer kit with power supply (Model ALS-SDA-86MEL)
- Microcontroller trainer kit with power supply (Model ALS-SDA-51ME)
- 8255 (Programmable peripheral Interface), 8279 (Programmable Keyboard Interface, 8259 (Programmable Interrupt Controller)
- ADC Interface Kit, DAC Interface Kit
- Stepper motor Interface(MODEL ALS-NIFC-01A)
- Traffic light controller (MODEL ALS-NIFC-11), Timer interface
- Dual DAC interface (MODEL ALS-NIFC-06A)
- 8-bit ADC interface(MODEL ALS-NIFC-07A)
- 8251A/8253 timer controller study card(MODEL ALS-NIFC-21)
- Digital Signal Processing Laboratory
- PCs with fixed /floating point DSP processors (Kit/ Add-on Cards) TMS320C5416, TMS320C6711, ADSP2181, ADSP21065
- Function generator(1MHz)
- CRO (30MHz)
- DSO
- MATLAB with Simulink (Signal Processing, Communication, Image Processing, Filter Design, Control Systems, Neural Networks, Fuzzy Logic, Model predictive Control tool box, Non-Linear control Design)
- Analog and Digital Communication Laboratory
- CRO (20 MHz)
- Function Generator (1MHz)
- Power Supply (0-30 Volts Variable)
- Pulse Generator
- Antenna Trainer
- AM/ FM Signal Generator
- 100MHz Oscillator
- Spectrum Analyzer
- RF Modules
- DSSS – 1 Trainer Modules
- DSO
- Buck, Boost & Fly back Converter
- AM Receiver Kit
- FM Receiver Kit
- TDM Trainer Kit
- PAM, PPM, PWM Trainer Kits
- PCM Trainer Kit
- Delta Modulation Kit / Differential pulse code modulation kit
- Line Coding & Decoding Kit
- ASK, PSK, FSK Trainer Kits
- Antenna Training System with Half wave dipole, Yagi and Loop Antennas
- VLSI Design Laboratory
- Computers with Xilinx ISE Simulator
- Xilinx Spartan 3 FPGA with 400k Gali density Trainer Kit
- Piggyback Altera FPGA Kit
- Universal Multivendor Development Kit (Traffic light, Stepper motor, real time clock)
- Electronic System Design Laboratory
- Process control timer kit
- Data Acquisition and storage kit
- PC based Data Acquisition
- Microprocessor based DC motor Speed Control
- 8085 Microprocessor Kit
- A/D Interface
- LVDT Trainer kit
- Microprocessor based strain gauge trainer kit
- Microprocessor based Temperature measurement kit
- Microprocessor based Pressure Transducer kit
- MATLAB
- Networks Laboratory
- Computers with NetSim Software installed.
- Wireless/ Ethernet LAN Trainer Kit (TETCOS- Model LT01)
- Data Communication Trainer kit
- Embedded Systems and IoT Design / Industrial IoT Lab
- Arduino uno
- Microcontroller: Atmega328P running at 16 MHz
- Memory: 32 KB Flash, 2 KB SRAM, 1 KB EEPROM
- Digital I/O Pins: 14 (6 PWM)
- Analog Input Pins: 6
- Operating Voltage: 5 volts, accepts 6-20 volts input
- Raspberry pi 4 model B
- Processor: Broadcom BCM2711 quad-core Cortex-A72 (ARM v8) 64-bit SoC at 1.5GHz
- RAM: 4GB, LPDDR4-3200 SDRAM options
- Connectivity: Dual-band 802.11b/g/n/ac Wi-Fi, Bluetooth 5.0, Gigabit Ethernet
- Ports: 2 × USB 3.0 and 2 × USB 2.0 ports, 2 × micro HDMI ports (up to 4Kp60 supported)
- Expansion: 40-pin GPIO header, 2-lane MIPI DSI display port, 2-lane MIPI CSI camera port
- ESP8266
- Microcontroller: Tensilica L106 32-bit microcontroller core.
- Clock Speed: Up to 80MHz.
- Memory: Typically 32KB of instruction RAM and 80KB of user data RAM.
- Connectivity: Integrated Wi-Fi 802.11 b/g/n support.
- GPIO Pins: Typically 17 GPIO pins for various input/output operations.
- Microwave and Optical Communication Laboratory
- Klystron power supply
- Klystron mount with Klystron tube -Gunn power supply
- Gunn oscillator
- PIN modulator
- Isolator & Circulator
- Attenuator
- Frequency meter-direct reading
- Slotted section
- Detector mount
- Slide screw tuner
- Horn antenna
- Fixed attenuator
- Magic TEE
- E-Plane TEE -H-Plane TEE
- Directional coupler
- VSWR meter
- CRO
- Power meter
- Radiation table
- Universal Waveguide stand
- Optical power source
- Fiber Optic Power meter
- fiber optic trainer Kit
- Multiplexer/Demultiplexer Kit
- Laser Trainer Kit - PIN Diode
- LED mounted source at wavelength 870nm - DSO
- Variable attenuator
- Tunable probe
- Screws and nuts
- BNC-BNC cables
- Cooling fan
- Microwave Signal Source
- RF power detector
- Yagi Antenna
- Die pole Antenna
- Patch Antenna -Antenna turn table
- Ring Resonator
- Power Divider
- Parallel line coupler
- 6db attenuator pad
- 50 ohm match termination
- Active filter
- RF cable Short length
- RF cable (SMA-SMA) 1m length -SMA-BNC Cable
- Circulator
- RF/IF Mixer
- Monopole Antenna
